ES 2024/2024e Setting up • 65
Parallel Menu
The default settings are bold.
Item Value Description
PARALLEL ENABLE; DISABLE Selects parallel (Centronics)
interface.
BI-DIRECTION ENABLE; DISABLE Selects bi-directional
communication.
ECP ENABLE; DISABLE Selects ECP mode.
ACK WIDTH NARROW; MEDIUM;
WIDE Sets ACK width for compatible
reception:
Narrow = 0.5 µS
Medium = 1.0 µS
Wide = 3.0 µS
ACK/BUSY
TIMING ACK-IN-BUSY;
ACK-WHILE-BUSY Sets output order for ACK and
BUSY during reception.
ACK IN BUSY: BUSY=LOW to the
end of the ACK pulse.
ACK WHILE BUSY: BUSY=LOW to
the center of the ACK pulse.
I-PRIME 3 MICRO SEC; 50
MICRO SEC;
DISABLE Sets or disables the i-Prime signal.
OFFLINE
RECEIVE ENABLE; DISABLE Enable = maintains reception
without changing the interface
signal, even though an alarm
occurs. The interface stays open
even if the ON LINE button is
pressed.
The interface issues a BUSY signal
only when the receive buffer is full.
