22 OKIPOS 425D
|
2) Insert the tip of roll paper into the groove of the rewinder as shown in the detail figure.
Then, turn the rewinder into the arrow direction to wind the roll paper around it 2 or 3 times.
o425_94.jpg and o425_95.jpg
3) Insert the flange into the rewinder (to the arrow direction 1) until it stops, then turn it into the arrow direction 2 to
lock.
4) Mount the rewinder on the printer.
Note: When using narrow roll paper (69.5 mm width), turn over the flange as the arrow (e) and then mount it
following the above procedures 3) and 4).
Note that the flange can be demounted in the reverse procedures to its mounting.
Note: This printer can use two kinds of roll paper. Their widths are 69.5mm+0.5mm and 76.2mm+0.5mm.
6. Close the printer cover.
