A - 4
10) Timing charts
a) Data receiving timing
• Compatible mode
PARALLEL DATA
(DATA BITs 1 to 8)
DATA STROBE
ACKNOWLEDGE
BUSY
0.5 µ s min.
0.5 µ s min.
0.5 µ s min.
0.5 µ s max.
0.5 µ s min.
0 min.
0 min. 0 min.
0.5 µ s to 10 µ s
0 min.
PARALLEL DATA
DATA STROBE
1 µ s min.
1 µ s min.
b) Data Receiving Timing (Burst Mode)
ACKNOWLEDGE
BUSY
6 7 4 5 2 3
DATA bit 3 DATA bit 7
FAULT
6 7 4 5 2 3
DATA bit 0 DATA bit 4
SELECT IN
. , - * +
DATA bit 1 DATA bit 5
PAPER END
& ' . $ , - " * +
DATA bit 2 DATA bit 6
c) Data Sending Timing (Nibble Mode)
