397
FINS Commands Addressed to EtherNet/IP Units or Built-in EtherNet/IP Ports
Appendix E
Response Codes
BROADCAST TEST RESULTS READ
Reads the results (number of times data received) of the broadcast test.
Command Block
Response Block
Parameters
Times Received (Response)
The number of times the data has been received normally during the broadcast send test is returned as a
hexadecimal number. The number of times received is cleared each time the result is read.
Response Codes
BROADCAST DATA SEND
Sends test data simultaneously to all nodes on the network.
Command Block
Parameters
Test Data (Command)
This command specifies the data to be sent to the specified nodes. Up to 1,460 bytes can be specified.
Response code
Description
0000
Normal end
1001
Command too large
1002
Command too small (No test data)
08 02
Command
code
08 02
Times
received
Response
code
Command
code
Response code
Description
0000
Normal end
1001
Command too large
08 03
Command
code
1,460 bytes max.
Test data
