60
Playback
1/1000
AUTO
MA
N
HAZE
SHD
W
PUSH
SEPIA
FR ON TLIG HT
BA C K LIG HT
FADE
TITLE
SP/SLP DA TE/TIME COUNTER QU ICK RE PA LY/ PA US E
S T OP
PL
AY/PAUSE
VCR
EJECT
Switch
STOP Button
Viewfinder
Eyepiece Focus
Control
PLAY/PAUSE
Button
Use the Viewfinder for Playback
You can see tapes using the viewfinder. There is no sound during
viewfinder playback.
To Play Back a Tape
1. Attach a power supply.
Attach the adapter/charger, charged
battery, or optional car cord.
2. Insert a tape.
• Slide EJECT up to open the cassette
compartment.
• Turn the tape wheel on the cassette
to remove any slack from the tape.
• Insert the cassette with the tape
wheel facing up and the tape
window facing out.
• Press on the PUSH button to lock
the cassette compartment closed.
3. Set the POWER switch to VCR.
The power indicator lights.
4. Adjust the viewfinder for a
comfortable viewing position.
VCR 66 66 66 66 66 Button
VCR 55 55 55 55 55 Button
PUSH Button
