12
2 Repeat Step 1 to connect the left speaker.
Note: Make sure the exposed tips of the speaker wires do not touch each other, and
that they are fully inserted into the gaps.
Connecting the receiver to an AC power outlet
Caution: Connect the AC power plug to a wall outlet only after all speakers are
connected to the receiver.
To connect the receiver to an AC power outlet:
1 Connect the female end of the AC power cord to the AC IN connector on
the back of the receiver.
2 Plug the other end of the AC power cable into a power outlet. The
standby indicator on the receiver turns on.
Cautions: To avoid risk of fire, and to prevent damage:
Do not use AC adapters other than the supplied AC adapter.
Do not use the supplied AC adapter for other equipment.
SPEAKER-OUT (4-8 Ohm)
R L
AC IN
Right (rear)
speaker Left (rear)
speaker
Receiver back
To AC power
outlet
Cable notch
