ROBERTS GOR DON ® BH- S ERI E S S UBM IT TAL S HE E T
© 2004 Roberts-Gordon BEFORE IN ST AL LATI ON AND OPER ATI ON OF HEATI NG E QUIPMENT, READ AND U NDERSTAND T HE INSTALL AT ION, OPERATIO N AND SERVICE MANUAL .
APPL ICATION S, ENGI NEE RING AND DET AI LE D GUID ANCE ON SYST EMS DE SIGN, INSTAL LATI ON AND PRODUCT PE RFORMANCE IS AVAI LABLE UPON RE QUEST. ROBERT S GORDON
® PRODUCT S ARE T O BE
INSTAL LE D ONL Y IN ACCORDANCE WI TH L OCAL L AWS, CODES AND REGUL AT IONS, AND ONLY BY A CONT RACT OR QUALI FIE D I N THE I NST ALL AT ION AND SE RVICE OF GAS-FIRE D HE AT ING EQUI PME NT.
STANDARD PARTS LIST
Contents of BH-Series Burner Carton
Part No. Description BH-40 BH-60 BH-80 BH-100 BH-115 BH-125 BH-140 BH-150 BH-175 BH-200
071XXXXX BH-Series Burner (Rate and Fuel Varies) 1 1 1 1 1 1 1 1 1 1
90709700 Blower Assembly with Cord 1 1 1 1 1 1 1 1 1 1
02568200 Gasket (Burner to Burner Tube) 1 1 1 1 1 1 1 1 1 1
90709801 Gasket (Blower to Burner) 1 1 1 1 1 1 1 1 1 1
170101NA Installation Manual 1 1 1 1 1 1 1 1 1 1
91201708 Pipe Nipple (Black) 1/2” x 4” 1 1 1 1 1 1 1 1 1 1
94273914 Hex Head Rolok 5/16 - 18 4 4 4 4 4 4 4 4 4 4
96411600 Split Lock washer 4 4 4 4 4 4 4 4 4 4
91412200 Flexible Gas Connector Assembly, 1/2” NPT 1 1 1 1 1 1 - - - -
91412203 Flexible Gas Connector Assembly, 3/4" NPT - - - - - - 1 1 1 1
91907302 S-Hooks 2 2 2 2 2 2 2 2 2 2
91911700 Outside Air Collar 1 1 1 1 1 1 1 1 1 1
94118106 #8 x 3/8 Hex Washer Head (for Outside Air Collar) 3 3 3 3 3 3 3 3 3 3
92311800 Keps Nut 4 4 4 4 4 4 4 4 4 4
03051503 Turbulator Adapter 1 1 1 1 1 - 1 - - -
03051504 Turbulator 2.5’ (76 cm), Aluminized Steel 2 4 4 1 3 - 1 - - -
03051505 Turbulator 2.5’ (76 cm), Stainless Steel 1 - - - - - - - - -
Contents of Core and Extension Packages
Core Packages Extension Packages
Hot Rolled Aluminized Hot Rolled Aluminized
Part No. Description 20 '
( 6 m )
30 '
( 9 m )
40 '
( 1 2m )
10 '
( 3m )
20 '
( 6m )
30 '
( 9m )
40 '
( 12 m )
10 '
( 3 m )
20 '
(6 m )
30 '
(9 m )
40 '
(1 2m )
10 '
( 3m )
20 '
( 6m )
30 '
( 9 m )
40 '
( 12 m )
91409300 Tube, Hot Rolled Steel, 10 ' (3m) 1 2 3 - - - - 1 2 3 4 - - - -
91409408 Tube, HT Aluminized, 10 ' (3m) - - - - 1 2 3 - - - - 1 2 3 4
03051101 Burner Tube, ALUMI-THERM
®
Steel, 10 ' (3m) 1 1 1 - 1 1 1 - - - - - - - -
03051601 Burner Tube, HT ALUMI-THERM
®
Steel, 10 ' (3m) - - - 1 - - - - - - - - - - -
01312700 Coupling Assembly 1 2 3 - 1 2 3 1 2 3 4 1 2 3 4
02750303 Standard Reflector, 8 ' (3.5m) 3 4 6 2 3 4 6 2 3 4 6 2 3 4 6
02750800 End Cap 2 2 2 2 2 2 2 - - - - - - - -
03090100 Tube and Reflector Hanger 3 4 5 2 3 4 5 1 2 3 4 1 2 3 4
91907302 S-Hook 3 4 5 2 3 4 5 1 2 3 4 1 2 3 4
03050010 Reflector Support Package (Strap, Wire Form, Screws) 2 3 5 1 2 3 5 2 3 4 6 2 3 4 6
91107720 U-Clip Package 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
90502700 Vent Adapter 1 1 1 1 1 1 1 - - - - - - - -
01318901 Tube Clamp Package 1 1 1 1 1 1 1 - - - - - - - -
Part Number
C
P2
0HRS
C
P3
0HRS
C
P4
0HRS
C
P
10A
LU
M
C
P
20A
LU
M
C
P
30A
LU
M
C
P
40A
LU
M
EX
P1
0H
R
S
EX
P2
0H
R
S
EX
P3
0H
R
S
EX
P4
0H
R
S
EX
P
10A
LU
M
EX
P
20A
LU
M
EX
P
30A
LU
M
EX
P
40A
LU
M
