ROBERTS GORDON ® BH- S ERI E S S UBM IT TAL S HE E T
© 2004 Roberts-Gordon BEFORE IN ST AL LATI ON AND OPER ATI ON OF HEATI NG E QUIPMENT, READ AND U NDERSTAND T HE INSTALL AT ION, OPERATIO N AND SERVICE MANUAL .
APPL ICATION S, ENGI NEE RING AND DET AI LE D GUID ANCE ON SYST EMS DE SIGN, INSTAL LATI ON AND PRODUCT PE RFORMANCE IS AVAI LABLE UPON RE QUEST. ROBERT S GORDON
® PRODUCT S ARE T O BE
INSTAL LE D ONL Y IN ACCORDANCE WI TH L OCAL L AWS, CODES AND REGUL AT IONS, AND ONLY BY A CONT RACT OR QUALI FIE D I N THE I NST ALL AT ION AND SE RVICE OF GAS-FIRE D HE AT ING EQUI PME NT.
End Piece and Reflector End Cap
90° Elbow
Fasten end piece
to brackets using two
#8 sheet metal screws
and replace reflector end cap.
Insert end piece
between grille and
brackets.
End Piece
Reflector
End Cap
Descr ipti on Part Number
End Piece 01365901
Insert
End Piece
between
grille and
brackets.
Joint Piece Cut grille bracket at
reflector joint piece.
Grille Brackets
Inside
Corner
Decorative Grille
Brackets
Joint Piece
