Wireless Router
RNX-G40 User Manual
1 Introduction
The WLAN AP Router is IEEE 802.11b/g WLAN AP router solution; setting SOHO and enterprise standard for
high performance, secure, manageable and reliable WLAN.
This document describes the steps required for the initial IP address assignment and other WLAN router
configuration. The description includes the implementation of the above steps.
1.1 Package contents
The package of the WLAN AP Router includes the following items
z
WLAN AP Router
z
AC to DC power adapter
z
Documentation CD
z
Antenna
z
RJ45 LAN cable
1.2 Product Specifications
Product Name
WLAN AP Router
Standard 802.11b/g(Wireless),
802.3(10BaseT), 802.3u(100BaseT)
Data Transfer Rate
54Mbps(Wireless), 1 OOMbps(Ethernet)
Modulation Method
CCK(802.1 lb), OFDM(802.1 lg)
Frequency Band
2.4GHz - 2.483GJz ISM Band, DSSS
RF Output Power
CCK< 17 dBm, OFDM< 13.5 dBm
Receiver Sensitivity
802.11b -80 dBm@10%, 802.llg -68 dBm@8%
Operation Range
30 to 280 meters (dependent on surroundings)
Antenna External
Antenna
LED
Power, Active (WLAN), Act/Link (Ethernet)
Security
64 bit/ 128 bit WEP, WPA, WPA2, port filtering, IP filtering,MAC
filtering, port forwarding and DMZ hosting
LAN interface
One 10/1 OOBaseT with RJ45 connector (WAN)
Four 10/1 OOBaseT with RJ45 connectors (LAN)
Power Consumption
12 V, 1A DC Power Adapter
Operating Temperature 0 ~ 50°C ambient temperature
Storage Temperature
-20 ~ 70°C ambient temperature
Humidity
5 to 90 % maximum (non-condensing)
Dimension
160 x 120 x 30 mm
- 6 -
