Wireless Router RNX-G40 User Manual
3.3.18 Management – Statistics
This page shows the packet counters for transmission and reception regarding to wireless, Ethernet LAN
and Ethernet WAN networks.
Screen snapshot - Management – Statistics
Item Description
Wireless LAN
Sent Packets
It shows the statistic count of sent packets on the wireless LAN interface.
Wireless LAN
Received Packets
It shows the statistic count of received packets on the wireless LAN interface.
Wireless LAN
Sent Packets
It shows the statistic count of sent packets on the Ethernet LAN interface.
Ethernet LAN
Received Packets
It shows the statistic count of received packets on the Ethernet LAN interface.
Ethernet WAN
Sent Packets
It shows the statistic count of sent packets on the Ethernet WAN interface.
Ethernet WAN
Received Packets It shows the statistic count of received packets on the Ethernet WAN
interface.
Refresh Click the refresh the statistic counters on the screen.
