Rosewill RNX-G400 User Manual
Page 29
Wireless Router
RNX-G40 User Manual
II WDS AP Table
This page is used to show WDS statistics
Screen snapshot - WDS AP Table
Item Description
MAC Address It shows the MAC Address within WDS.
Tx Packets
It shows the statistic count of sent packets on the wireless LAN interface.
Tx Errors
It shows the statistic count of error sent packets on the Wireless LAN interface.
Rx Packets
It shows the statistic count of received packets on the wireless LAN interface.
Tx Rare (Mbps) It shows the wireless link rate within WDS.
Refresh
Click to refresh the statistic counters on the screen.
Close
Click to close the current window.
3.3.9 Site Survey
This page is used to view or configure other APs near yours.
Screen snapshot - Wireless Site Survey
- 28 -
