Wireless Router
RNX-G40 User Manual
Item Description
Disable Wireless LAN
Interface
Click on to disable the wireless LAN data transmission.
Band
Click to select 2.4GHz(B) / 2.4GHz(G) / 2.4GHz(B+G)
Mode
Click to select the WLAN AP / Client / WDS / AP+WDS
wireless mode.
Site Survey
The Site Survey button provides tool to scan the wireless
network. If any Access Point or IBSS is found, you could
choose to connect it manually when client mode is
enabled. Refer to 3.3.9 Site Survey.
SSID
It is the wireless network name. The SSID can be 32
bytes long.
Channel Number
Select the wireless communication channel from
pull-down menu
Associated Clients
Click the Show Active Clients button to open Active
Wireless Client Table that shows the MAC address,
transmit-packet, receive-packet and transmission-rate for
each associated wireless client.
Enable Mac Clone
(Single Ethernet Client)
Take Laptop NIC MAC address as wireless client MAC address. [Client Mode
only]
Apply Changes
Click the Apply Changes button to complete the new
configuration setting.
Reset
Click the Reset button to abort change and recover the
previous configuration setting.
3.3.5 Wireless - Advanced Settings
These settings are only for more technically advanced users who have a sufficient knowledge about wireless
LAN. These settings should not be changed unless you know what effect the changes will have on your
WLAN AP Router.
- 20 -
