Figure 4.9 Pin layout of the 26-wire normal-pitch cable
Table 4.8 26-wire normal-pitch cable pin assignments
*1 EV
DD
does not input the power supply from the target system, but outputs it to the target system
from the power circuit on the M34502T-MCU.
*2 X
IN
is input from oscillator circuit board OSC-2 on the M34502T-MCU and cannot be input from
the oscillator circuit on the target system.
1
2
3
4
5
6
7
8
9
10
11
12
13
EV
DD
* 1
V
SS
NC (X
IN
* 2 )
NC (X
OUT
)
NC (CNV
SS
)
ERESET
EP2
1
/A
IN1
EP2
0
/A
IN0
ED
5
ED
4
ED
3
ED
2
NC
26
25
24
23
22
21
20
19
18
17
16
15
14
P3
0
/A
IN2
P3
1
/A
IN3
EP0
0
EP0
1
EP0
2
EP0
3
EP1
0
EP1
1
EP1
2
/CNTR
EP1
3
/INT
ED
0
ED
1
NC
