Runco VX-2i Owner’s Operating Manual

Figure 3-4. Vertical Lens Shift

Figure 3-5. Horizontal Lens Shift

Base plate

to lens center =

approx. 5-6" (depending

on the amount of lens shift)

50% Height

Lens Shift

(0.5 x H)

100% Height

Lens Shift

(1.0 x H)

150% Height

Lens Shift

(1.5 x H)

Screen Center

Note:

This is a general example of lens shift. Lenses vary in their shift capabilities. No particular

lens is used in this example.

Screen Center

100% Width Lens Shift

(1.0 x W)

50% Width Lens Shift

(0.5 x W)

150% Width Lens Shift

(1.5 x W)

Screen Width (W)

Note:

This is a general example of lens shift. Lenses vary in their shift capabilities. No particular

lens is used in this example.
