Runco VX-2i Owner’s Operating Manual
3.2
Quick Setup
Table 3-1 gives a quick overview of the VX-2i installation process. The sections following
this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step
Procedure
For Details, Refer to
page...
1
Choose a location for the projector
2
Connect signal sources to the projector
3
Connect external controller to RS-232 port (optional)
4
Connect other home theater components to 12-volt trigger
outputs (optional)
5
Apply power to the projector
6
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation
7
Lens adjustments: projected image size (zoom), position
(shift) and focus
8
Projector calibration: adjust the following
for each input,
starting with Component SD; save settings when finished:
• Aspect ratio
• Brightness
• Contrast
• Color level
• Tint
• Input position
Note
