Table

5.

InfoPrint

XT

NOP

structured

field

format

(continued)

Offset

Length

Value

Description

1

2

8-32767

Total

length

of

the

structured

field.

This

does

not

include

the

carriage

control

byte.

3

3

X'D3EEEE'

MO:DCA

No

Operation

structured

field

identifier.

6

1

X'00'

Flags.

InfoPrint

XT

always

uses

X'00'

.

7

2

X'0000'

Reserved

bytes.

InfoPrint

XT

always

uses

X'0000'

.

9

8

AIOX2AFP

This

parameter

specifies

that

InfoPrint

XT

generated

the

NOP

structured

field.

InfoPrint

XT

generates

the

parameter

value

in

EBCDIC:

X'C1C9D6E7F2C1C6D7'

.

17

2

X'nnnn'

The

level

of

the

InfoPrint

XT

Structured

Field

Data.

The

current

level

is

X'0000'

.

19-n

n

variable

This

is

the

actual

data

for

the

structured

field.

Its

format

depends

on

the

level.

See

InfoPrint

XT

AIOX2AFP

NOP

level

X'0000'

format

shows

the

format

of

the

InfoPrint

XT

AIOX2AFP

level

X'0000'

NOP,

which

consists

of

four

parts.

Table

6.

InfoPrint

XT

NOP

level

X'0000'

format

Offset

Length

Description

19

8

An

EBCDIC

keyword

that

describes

the

InfoPrint

XT

information.

See

27

1

The

flag

byte.

28

2

The

length

of

any

associated

data.

30-n

n

The

data

itself,

if

any.

InfoPrint

XT

AIOX2AFP

NOP

keywords

InfoPrint

XT

uses

these

keywords

in

the

NOP

structured

fields

that

it

generates:

CTLHEADR

(X'C3E3D3C8C5C1C4D9')

InfoPrint

XT

generates

one

CTLHEADR

record

at

the

beginning

of

each

job

and

uses

it

to

identify

whether

the

AFP

data

stream

can

contain

XRXOTEXT

records.

The

values

for

its

flag

byte

at

offset

27

are:

Bit

0:

Specifies

whether

the

data

stream

can

contain

XRXOTEXT

records.

1

indicates

that

the

data

stream

can

contain

XRXOTEXT

records.

0

indicates

that

the

data

stream

does

not

contain

XRXOTEXT

records.

Bit

1:

Specifies

whether

the

data

stream

can

contain

XRXCDJDE

records.

1

indicates

that

the

data

stream

can

contain

XRXCDJDE

records.

0

indicates

that

the

data

stream

does

not

contain

XRXCDJDE

records.

Bit

2:

Reserved

for

future

use.

Bit

3:

Reserved

for

future

use.

Bit

4:

Reserved

for

future

use.

Bit

5:

Reserved

for

future

use.

Bit

6:

Reserved

for

future

use.

32

InfoPrint

XT

Guide

|
|
|
