Figure 1.1 connecting ferrite core – Renesas SuperH SH7600 Series User Manual
Page 9
3
For EMI countermeasure, use the ferrite core by connecting the user interface cable.
When the user interface cable is connected with the emulator or user system, connect the ferrite
core in the user system as shown in figure 1.1.
User interface cable
Host computer (PC with PC card slot)
E10A emulator
PC card slot
PC
PC
Card
User system
User system connector
Ferrite core
Figure 1.1 Connecting Ferrite Core
