5
1.3 Installing the H-UDI Port Connector on the User System
Table 1.3 shows the recommended H-UDI port connectors for the emulator.
Table 1.3 Recommended H-UDI Port Connectors
Connector Type Number Manufacturer Specifications
DX10M-36S Screw type 36-pin connector
DX10M-36SE,
DX10G1M-36SE
Hirose Electric Co., Ltd.
Lock-pin type
14-pin connector 2514-6002 Minnesota Mining &
Manufacturing Ltd. 14-pin straight type
Note: When the 36-pin connector is used, do not connect any components under the H-UDI
connector. When the 14-pin connector is used, do not install any components within 3 mm
of the H-UDI port connector.
1.4 Pin Arrangement of the H-UDI Port Connector
Figures 1.2 and 1.3 show the pin arrangement of the 36-pin and 14-pin H-UDI port connectors,
respectively.
Note: Note that the pin number assignment of the H-UDI port connector shown below differs
from that of the connector manufacturer.
