11
1
TCK
TMS
RESET
TDI
TDO
TRST
ASEBRKAK
GND
GND
GND
GND
GND
GND
2
3
4
5
6
7
ASEMD0
8
9
11
10
12
13
14
TCK
RESETP
TMS
TDO
TDI
TRST
ASEBRKAK
NC
SH7630
VccQ (3.3 V) VccQ (3.3 V)
H-UDI port connector
(14-pin type)
Reset signal
4.7 k
Ω 4.7 k
Ω
1 k
Ω
Figure 1.5 Recommended Circuit for Connection between the H-UDI Port Connector and
MPU (14-Pin Type)
