Raypak B6000 User Manual
Page 11
WATER TEMPERATURE SENSOR INSTALLATION (Domestic Hot Water Supply)
Page 11
SIMPLIFIED DIAGRAM OF TYPICAL PIPING
(PIPING LAYOUT MAY VARY PER SPECIFIC APPLICATION)
AIR TEMPERATURE SENSOR MUST BE INSTALLED ACROSS AIR TEMPERATURE
SENSOR CONTACTS. THE SENSOR IS NOT ACTIVATED AND CAN BE LEFT
STORED IN B6000 ENCLOSURE.
BOILER
HOT
WATER
SUPPLY
IMMERSION WELL
WATER SENSOR
1/2 NPT
OUTLET
INLET
COLD
WATER
STORAGE
TANK
INLET
OUTLET
B6000
