9
5. Plug the modular cord’s other end
into the wall plate jack, then align
the bracket’s keyhole slots with the
wall plate studs and slide the base
downward to secure it.
6. Plug the adapter into a standard AC
outlet.
7. Press and lift out the handset
holder, flip it over as shown, then
snap it back into place so it holds
the handset.
8. Lift the base’s antenna to a vertical
position.
Note: To mount the phone directly on a
wall, you need two screws (not supplied)
with heads that fit into the keyhole slots
on the bottom of the base.
Follow Steps 1, 3, 4, and 6–8 under “On
a Wall Plate or Wall,” then follow these
additional instructions for placement on
a wall.
1. Drill two holes 3 15 /
16
inches (100 mm)
apart. Then thread a
screw into each hole,
letting the heads
extend about
3 /
32
inch
(3 mm) from the wall.
2. Plug one end of the supplied long
modular cord into the TEL LINE jack
at the back of the base.
3. Align the bracket’s keyhole slots
with the mounting screws and slide
the base downward to secure it.
RING VOL
OF F-LO-HI
