8
4. Route the adapter’s cord through
the strain relief slot on the bottom of
the base.
5. Plug the adapter into a standard AC
outlet.
6. Lift the base’s antenna to a vertical
position.
On a Wall Plate or Wall
1. Insert the two tabs at the top of the
narrow end of the supplied bracket
into the base’s upper tab slots as
shown, then press down on the
bracket’s latches and insert them
into the lower slots.
2. Plug one end of the supplied short
modular cord into the TEL LINE jack
on the back of the base.
3. Insert the supplied AC adapter’s
barrel plug into the DC IN 9V jack.
4. Route the adapter and modular
cords through the grooves on the
bracket.
RING VOL
OF F-LO-HI
RING VOL
OF F-LO-HI
RING VOL
OF F-LO-HI
