Page 5

Connecting the Unit

MinIT Notes:

1. Use only the power supply provided with the unit. The

use of any other power supply may damage the unit.

2. The Power Button on the top of the unit will be lit

(orange) when there is power to the unit. The unit will
not start until you press the button. Then it will turn
green.

3. The correct way to power down the unit is from the

Start button or the MinIT Root Menu. See the
Technical Support section of the manual for more
information.

4. The USB ports on the front of the unit support USB

Keyboard or Mouse.

The headphone jack can be used for powered speakers
or amplified headphones.

Power

Video

Mouse

Keyboard

Parallel

( local printer )

Ethernet
