Runco CL-610 Series Owner’s Operating Manual

29

PRE

L

IMINAR

Y

4.1
Selecting Video
Memory

• Press the MEM1 button on the remote control

to recall settings for the current input from the
“Memory 1” memory preset.

• Press ISF NT (Night) to recall settings for the current input from the “ISF Night”

memory preset.

• Press ISF DAY to recall settings for the current input from the “ISF Day” memory

preset.

Press FACT to recall the factory-default settings for the current input. An on-screen
confirmation message appears. Press FACT again to confirm.

4.2
Selecting an Aspect
Ratio

Use these buttons to select the appropriate aspect
ratio for the type of program material being viewed.
For more information on aspect ratios, refer to Table
4-1
.

4.3
Selecting An Input
Source

When you turn on the CL-610, it switches to the last
selected input and looks for a valid signal.

Use these buttons on the remote control to select an
input source directly.

4.4
Using
Picture-In-Picture and
Picture-By-Picture
(PIP/PBP)

For PIP and PBP purposes, there are two groups of
inputs separated by their display modes:

• Video (SD) group: Video, S-Video and

Component 1 inputs.

• Graphic (HD) group: HDMI and Component 2/RGB inputs.

PIP and PBP show one input from the Graphic group within or beside one input from the
Video group respectively.

• Press PBP to enable the PBP function. Press PBP again to switch the screens left to

right. Press PBP again to turn PBP off.

• Press ACTIVE to switch to the active window. (You can only switch inputs in the active

window.)

• Press PIP to enable the PIP function. Press PIP again to switch the main window.

Press PIP again to turn PIP off.

• To adjust the size of the PIP window, press PIP+ or PIP-.

• Adjust the position of the PIP window with the arrow buttons (

,

,

,

).

4. Operation

MEM1

FACT

ISF

DAY

ISF

NIGHT

ANA

16X9

VWIDE

LBOX

4X3

CINEMA

VCINE

2

1

VID

S-VID

COMP1

RGBHD

HDMI

COMP2

PBP

PIP

PIP+

ACT

PIP-
