Installation
14 Runco CL-610 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
3.2
Quick Setup Table 3-1 gives a quick overview of the CL-610 installation process. The sections
following this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step Procedure
For Details, Refer to
page...
1 Choose a location for the projector 15
2 Mount the projector 18
3 Connect signal sources to the CL-610 19
4 Connect external controller to RS-232 port (optional) 23
5
Connect 12-volt trigger output to retractable screen or
other, +12-volt trigger-activated equipment (optional) 24
6 Apply power to the projector 24
7 Change the OSD Language (optional) 25
8
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation 25
9
Primary lens adjustments: projected image size (zoom) and
focus 25
10
Install CineWide anamorphic lens
(CL-610/CineWide and CL-610LT/CineWide only)
26
11
CineWide lens adjustments: position, angle, geometry and
focus 27
12
Projector calibration: adjust the following for each input;
save settings when finished:
• Aspect ratio
• Brightness
• Contrast
• Color level
• Tint
• Input position 37 through 43
Note
