Rgbhv source connections, Figure 3-5 . rgbhv source connections, 5. rgbhv source connections – Runco VISTAGE V-50HD User Manual
Page 34: Pre l iminar y
20
Vistage™ Series Flat-Panel Display Installation/Operation Manual
PRE
L
IMINAR
Y
RGBHV Source Connections: Connect personal computers and/or other RGB sources
to the HD1 and/or HD2 inputs as shown in Figure 3-5.
Figure 3-5. RGBHV Source Connections
Pr
R
Pb
B
Y
G
HD1
HD2
H
V
or
Computer
RGB Camcorder
Green
Blue
Red
H-Sync
V-Sync
