1.
REMOTE CONTROL SENSOR
Receives the signals from the remote control.
2.
STANDBY INDICATOR
Lights blue to indicate that the V-50HD/V-63HD is in standby mode; otherwise, it is
off.
3.
DISPLAY STAND
Optional accessory for table-top installations.
4.
SPEAKER BAR
Optional accessory that can be mounted to the bottom of the panel.
Rear-Panel Connectors
Figure 2-3 shows the rear-panel connector locations on the V-50HD/V-63HD.
Figure 2-3. V-50HD/V-63HD Rear Panel
➤
SECONDARY
INPUT
SERVICE
PORT
PRIMARY
INPUT
SECONDARY
INPUT
SERVICE
PORT
PRIMARY
INPUT
SECONDARY
INPUT
SERVICE
PORT
PRIMARY
INPUT
V-50HD
V-63HD
1
2
1
2
1
(with cover plate
removed)
(with cover plate removed)
2
