Troubleshooting – Roland DP90 User Manual
Page 50
Troubleshooting
Symptom
Cause/Action
Page
The wrong instrument is selected
when you press the [E . Piano],
[Strings], or [Other] button
Tone buttons [E. Piano] [Strings] [Other] also operate as buttons that select “Recommended Tones.”
Connecting a commercially-available CD-ROM drive to the USB memory port and selecting a song from a CD-ROM produced for
the VIMA (VIMA TUNES) will automatically cause sounds appropriate for that song to be assigned to the [E. Piano], [Strings], and
[Other] Tone buttons, so that you can select “recommended” sounds by pressing one of these buttons.
Effect does not apply
When you are using Dual play or Split play, and different effects are specified for the two selected tones, the effect will not be
applied to Tone 2 (when using Dual play) or the left-hand tone (when using Split play).
–
Reverberation remains even if You
defeat the Ambience effect
The unit’s piano sound faithfully simulates the depth and resonance of an acoustic piano, and this may give the impression of
reverberation even if you’ve defeated the Ambience effect.
Also, you may be able to eliminate some reverberation by reducing the value set for “Cabinet Resonance.”
The sound of the higher notes
suddenly changes from a certain
key
On an acoustic piano, the approximately one and a half octaves of notes at the top of the keyboard will continue sounding
regardless of the damper pedal. These notes also have a somewhat different tonal character. The unit faithfully simulate this
characteristic of acoustic pianos. On the unit, the range that is unaffected by the damper pedal will change according to the key
transpose setting.
–
High-pitched ringing is heard
If you hear this in headphones:
Piano sounds that have a brilliant and crisp character contain substantial high-frequency components that may sound as though
a metallic ringing has been added. This is because the character of an actual piano is being faithfully reproduced, and is not a
malfunction.
This sound can be adjusted by modifying the following settings.
• String Resonance (p. 45)
• Ambience (p. 18)
If you don’t hear this in headphones:
It is likely that there is some other reason (such as resonances within the unit). Please contact your dealer or a nearby Roland
service center.
–
Low notes sound wrong, or are
buzzy
If you set the volume to the maximum setting, the sound may be distorted depending on how you perform.
If this occurs, turn down the volume.
–
If you don’t hear this in headphones:
Performing at high volumes may cause the speakers or objects near the unit to resonate. Fluorescent lights or glass doors may
also resonate sympathetically. In particular, this is more likely to occur for lower notes and higher volumes. You can take the
following measures to minimize resonances.
• Locate the speakers 10–15 cm (4–6 inch) away from walls or other surfaces.
• Keep the volume down.
• Move away from the objects that are resonating.
If you hear this in headphones:
It is likely that there is some other reason. Please contact your dealer or a nearby Roland service center.
–
Song does not play correctly
Only the sound of a particular
instrument in a song does not
play
Could a part be muted?
If the button indicator is out, the music on that part is not heard. Press the part button so the indicator is illuminated.
Sound is heard from a muted part
Could the part mute volume be set to other than “0”?
If you set this to “0,” the sound of a muted part will be completely inaudible.
Song volume is low /
Volume differs between recording
and playback
Could the Song Balance volume be lowered?
Can’t play back a song saved in
USB flash drive
Could the Audio files of the format be played?
Audio files of the following format can be played back.
• File extension “.WAV”
• 16-bit linear
• “44.1 kHz” sampling rate
Is the filename extension “MID”?
Files with other filename extensions cannot be handled as song data.
–
Song tempo becomes unstable
When playing a song from USB flash drive, the tempo may become unstable if there is an excessive amount of performance data.
–
Song name in USB flash drive is
not shown
The song name will not be shown if the song information in the file is empty or consists only of spaces.
–
Is the filename extension “MID”?
Files with other filename extensions cannot be handled as song data.
–
Song names can consist only of English letters, numerals, certain symbols, and single-byte characters from the Japanese
syllabary; the unit is unable to correctly display the name if other characters are used.
–
Can’t record / play back
Can’t record SMF
Has one of the part buttons for recording been selected?
Can’t record audio
Is a USB flash drive connected to the USB memory port?
–
The recorded performance
disappeared
Your recorded performance will disappear if you switch off the unit’s power or select a song.
There is no way to recover the lost performance. Before you turn off the power, save your recorded performance in the internal
memory or the USB flash drive.
–
Limitations regarding audio files
• Ambience will not be applied to audio files (p. 18).
• The Part Mute function cannot be used when playing audio files (p. 26).
• Audio data cannot be saved in the unit’s internal memory. In order to record audio, you must connect a USB flash drive (separately sold) (p. 29, p. 33, p. 34).
• You can’t rename an audio file (p. 38).
• Audio files cannot be copied (p. 40).
50
