Chapter 3 I/O Information
© National Instruments Corporation 3-7 NI PXIe-8130 User Manual
Note The Ethernet controller can perform an automatic crossover, thus eliminating the
need for crossover cables.
Table 3-5. 10/100/1000 LAN Connector LED States
LED Color LED State Condition
Top Green
Off LAN link is not established.
On (steady state) LAN link is established.
On (brighter and pulsing) The controller is communicating with another
computer on the LAN.
Bottom
(None) Off 10 Mbit/sec data rate is selected.
Green On 100 Mbit/sec data rate is selected.
Amber On 1000 Mbit/sec data rate is selected.
