Chapter 2 Installation and Configuration
© National Instruments Corporation 2-19 NI PXIe-8130 User Manual
Figure 2-4 shows the location of the LabVIEW RT configuration switches.
The switches are shown in the OFF position.
Figure 2-4. LabVIEW RT Configuration Switches
Drivers and Software
Your hard drive includes a directory called images in its root that
contains software and soft copies of manuals for the peripherals. The
directory structure under the
images directory is logically organized into
several levels.
In the images directory, you will find a manuals directory,
an os directory, and a drivers directory.
1 Switch 1—Boot LabVIEW RT
2 Switch 2—Boot Safe Mode
3 Switch 3—Disable Startup VI
4 Switch 4—Reset IP Address
3
2
1
4
