© National Instruments Corporation A-1 SCXI-1125 User Manual
A
Specifications
This appendix lists the specifications for the SCXI-1125 modules. These
specifications are typical at 25 °C unless otherwise noted.
Input Characteristics
Note Refer to Tables 5-1 and 5-2 for extended range using the SCXI-1313A, SCXI-1327,
and TBX-1316.
Table A-1. Input Signal Range Versus Gain
Overall Gain Overall Voltage Range
SCXI-1125
Gain
1 ±5 V
peak
or VDC 1
2 ±2.5 V
peak
or VDC 2
5 ±1 V
peak
or VDC 5
10 ±500 mV
peak
or VDC 10
20 ±250 mV
peak
or VDC 20
50 ±100 mV
peak
or VDC 50
100 ±50 mV
peak
or VDC 100
200 ±25 mV
peak
or VDC 200
250 ±20 mV
peak
or VDC 250
500 ±10 mV
peak
or VDC 500
1000 ±5 mV
peak
or VDC 1000
2000 ±2.5 mV
peak
or VDC 2000
