12-6 User’s Reference Guide
■ LT (LocalTalk on the PhoneNET) if the optional AppleTalk feature set is installed
The right side of the table lists the total number of occurrences of each of six types of communication
statistics:
Rx Bytes: The number of bytes received
Tx Bytes: The number of bytes transmitted
Rx Packets: The number of packets received
Tx Pkts: The number of packets transmitted
Rx Err : The number of bad Ethernet packets received
Tx Err: The number of errors occurring when Ethernet packets are transmitted simultaneously by nodes on the
LAN
E E E Evvv vee e en n n ntttt h h h hiiiisssstttto o o orrrriiiiee e essss
The Netopia R5000 Series Router records cer tain relevant occurrences in event histories. Event histories are
useful for diagnosing problems because they list what happened before, during, and after a problem occurs.
You can view two different event histories: one for the router’s system and one for the WAN. The Netopia
R5000 Series Router’s built-in batter y backup prevents loss of event histor y from a shutdown or reset.
The router’s event histories are structured to display the most recent events first and to make it easy to
distinguish error messages from informational messages. Error messages are prefixed with an asterisk. Both
the WAN Event Histor y and Device Event Histor y retain records of the 128 most recent events.
In the Statistics & Logs screen, select WAN Event History. The WAN Event Histor y screen appears.
• WAN Event Histor y
Statistics & Logs
Main
Menu • Device Event Histor y
