Getting started

Figure 2: Installing the battery pack

Installing the charger

To install the charger, perform the following steps:

1. Place the charger on a flat surface.

2. Connect the AC adapter cable to the terminal on the bottom of the

charger.

3. Connect the adapter to an electrical outlet.

4. Place the handset on the charger as shown in

Figure 3

Note: (4075 only) The 4075 Handset charger has a slot that you can
use to charge a battery pack without having the battery pack installed
in the phone. See

“Charging the battery pack (4075 only)” (page 220)

for more details.

Handset

Battery

pack
