NI WLS/ENET-9163 Carrier User Guide and Specifications 2 ni.com
Dimensions
Figure 2 shows the NI WLS/ENET-9000 Series device dimensions.
Figure 2. NI WLS/ENET-9000 Series Device Dimensions
Safety Guidelines
Operate the NI WLS/ENET-9000 Series device only as described in this
user guide.
Note Some C Series I/O modules may have more stringent certification standards than the
NI WLS/ENET-9163 carrier, and the combined system may be limited by individual
component restrictions.
Caution The NI WLS/ENET-9000 Series device is not certified for use in hazardous
locations.
NATIONAL
INSTRUMENTS
ERR
O R
ST
ATUS PWR
7.179 in.
(182.36 mm)
8.436 in.
(214.27 mm)
3.745 in.
(95.11 mm)
4.012 in.
(101.90 mm)
1.466 in.
(37.24 mm)
1.356 in.
(34.43 mm)
WLS LINK
