© National Instruments Corporation 15 NI WLS/ENET-9163 Carrier User Guide and Specifications
LED Indicators
The LED indicators for the NI WLS/ENET-9000 Series device are listed in
Table 2.
Table 2. LED State/Device Status
LED Description Color LED State Device Status
10/100 Green On Connected at 100 Mbps
Off No Ethernet connection or 10 Mbps
connection
LINK/ACT Yellow On Ethernet link
Off No Ethernet connection
Blinking Ethernet activity
POWER Green On Power on
Off Power off
STATUS Yellow On Device firmware booting or
resetting to factory default
Off Normal operation
1 Blink No C Series module detected
2 Blinks Firmware/FPGA image corrupted,
update firmware through MAX
3 Blinks Firmware error, reboot
ACTIVE Green On A DAQ task is running on the
device
Off Device available
WLS LINK * Green On Connected and authenticated
Off Not connected to access point
* NI WLS-9163 Only
