NETGEAR 10/100/1000 Mbps Gigabit Ethernet Adapter GA311 User Manual
1-4
v1.0, February 2007
If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the
carton, including the original packing materials, in case you need to return the product for repair.
To qualify for product updates and product warranty registrations, fill out the registration
information within 30 days of purchase. For priority service, register online on the NETGEAR
Web page at:
http://www.NETGEAR.com
You can also fill out and return the Warranty & Registration Card that is included in your product
package.
Hardware Description
As illustrated in the figure below, the GA311 Gigabit Ethernet Adapter has an RJ-45 connector
port and four LEDs.
Figure 1-1
The front panel of the GA311 has four LEDs: one for each port speed option (10 Mbps,100 Mbps,
and 1000 Mbps) to indicate which link is active, and one LED for the data transfer status.
