Reference Manual for the Integrated ADSL Modem and Wireless Router with Voice, Model
Managing Your Network 6-7
v1.0, September 2006
Click the Show Statistics button to display modem router usage statistics, as shown below:
Downstream Speed The speed at which the modem is receiving data from the ADSL line.
Upstream Speed The speed at which the modem is transmitting data to the ADSL line.
VPI The Virtual Path Identifier setting.
VCI The Virtual Channel Identifier setting.
Wireless Port These are the settings as set in the Wireless Settings page; see
“Understanding Wireless Settings” in Chapter 3 for details.
Name (SSID) The Service Set ID, also known as the wireless network name.
Region The country where the unit is set up for use.
Channel The current channel, which determines the operating frequency.
Wireless AP Indicates if the Access Point feature is disabled or not. If not enabled, the
Wireless LED on the front panel will be off.
Broadcast Name Indicates if the DG834GV is configured to broadcast its SSID.
Figure 6-4
Table 6-1. Menu 3.2 - Modem Router Status Fields (continued)
Field Description
