Technical Information
116
- ENGLISH
Appendix
Control commands via LAN
When WEB Control administrator rights password is set (Protect mode)
J
Obtain the IP address and port number (Initial set value = 1024) of the projector and 1 )
make a request for connection to the projector.
You can obtain both IP address and port number from the menu screen of the projector.
IP address : Obtain from MAIN MENU ⇒ [NETWORK] ⇒ [NETWORK STATUS]
Port No. : Obtain from MAIN MENU ⇒ [NETWORK] ⇒ [NETWORK CONTROL] ⇒ [COMMAND PORT]
There is a response from the projector. 2 )
Response data
Data section Blank Mode Blank
Random number
section
Termination
symbol
“NTCONTROL”
(ASCII string)
‘ ’
0x20
‘1’
0x31
‘ ’
0x20
“zzzzzzzz”
(ASCII code hexadecimal
number)
(CR)
0x0d
9 bytes 1 byte 1 byte 1 byte 8 bytes 1 byte
Mode : 1 = Protect mode
Generate a 32-byte hash value from the following data using MD5 algorithm. 3 )
“xxxxxx:yyyyy:zzzzzzzz”
xxxxxx : Administrator rights user name for WEB CONTROL
(Default user name is “admin1”)
yyyyy : Password of above administrator rights user
(Default password is “panasonic”)
zzzzzzzz : 8-byte random number obtained in Step 2)
Transmit using the following command format.
Transmitted data
Header Data section
Termination
symbol
Hash value
(See above
)
‘0’
0x30
‘0’
0x30
Control command
(ASCII string)
(CR)
0x0d
32 bytes 1 byte 1 byte Undefined length 1 byte
Receive data
Header Data section
Termination
symbol
‘0’
0x30
‘0’
0x30
Control command
(ASCII string)
(CR)
0x0d
1 byte 1 byte Undefined length 1 byte
Error response
Error message Termination symbol
“ERR1”
“ERR2”
“ERR3”
“ERR4”
“ERR5”
“ERRA”
Undefined control command
Out of parameter range
Busy state or no-acceptable period
Timeout or no-acceptable period
Wrong data length
Password mismatch
(CR)
0x0d
4 bytes 1 byte
