2.2 Installation of the Hybrid IP-PBX
56 Installation Manual
2.2.10 Wall Mounting (AC Adaptor)
Mounting on Wooden Wall
1. Place the reference for wall mounting (on the following page) on the wall to mark the two screw
positions.
2. Install the screws and washers (included) in the wall.
Notes
• Make sure that the screw heads are at the same distance from the wall.
• Install the screws perpendicular to the wall.
3. Hook the AC adaptor on the screw heads.
Note
Be careful not to drop the AC adaptor.
110 mm
(4-5/16 in)
Washer
Drive the screw
to this position.
