Closing the covers – Panasonic HYBRID IP-PBX KX-TDA50 User Manual
Page 38
2.2 Installation of the Hybrid IP-PBX
38
Installation Manual
Closing the Covers
1.
Close the front cover, then tighten the three screws.
2.
Attach the rear hooks on the cable cover to the main unit, then swing the cable cover closed so that the
front hooks fit in place.
3.
Slide the cable cover down until it locks.
Screw
Cable Cover
