2.7 Connection of 2.4 GHz Portable Stations
Installation Manual 105
b. Overlap the CS coverage areas of at least 2 CSs at any location in the installation site.
c. Make sure that the radio signal strength level is greater than "3" at any location in the service area
required by the user.
Referring to the Stored Scan Data
Using the KX-TD7680
Using the KX-TD7690
CS no. 1 CS no. 2
CS no. 3 CS no. 4
Press 1, 9, and POWER
for more than 2 seconds. 0 to 9
Scan Data No. 1 9 1
Display example:
When there is scan data
When there is no scan data
NO.1
CS No.2 LEVEL: 9
NO.0
NOT SAVED
To the Desired Scan Data No.
Press 1, 9, and POWER
for more than 2 seconds. 0 to 9
Scan Data No. 1 9 1
Display example:
When there is scan data
When there is no scan data
NO.1
CS No.2 LEVEL: 9
NO.0
NOT SAVED
To the Desired Scan Data No.
