3.2 Connection

Installation Manual

131

3.2

Connection

3.2.1

Connection

Serial Interface Connection

Note

For pin assignments and maximum cabling distance, refer to "2.9.1 Connection of Peripherals".

LAN Connection via IP-GW4 Card

Note

For pin assignments and maximum cabling distance, refer to "2.3.3 IP-GW4 Card (KX-TDA5480)".

PC

PC

To USB Port

To COM Port

USB Port

RS-232C Port

PC

Switching Hub

To network port

RJ45
