2.2 Installation of the Hybrid IP-PBX
Installation Manual 41
2.2.6 Installing/Removing the Optional Service Cards
Slot Position
Slot Restrictions
The following table shows the slot restrictions. " " indicates that the slot supports the optional service card.
* 1 Slots 10 and 11 accept only cards that do not have external ports. Therefore, these slots do not have
removable cover plates.
* 2 Slot 02 has an LCOT4 card pre-installed.
* 3 Slot 01 contains the pre-installed Super Hybrid Ports. No optional service card can be installed.
Card Slot Number
Type Max 02 03 04 05 06 07 08 09 10 11
LCOT4 3 *1
HLC4
1 *2
DLC4
SLC4
PLC4
IP-GW4 1
IP-EXT4 1
DLC8
2 *3 SLC8
PLC8
DPH4 1
ECHO8 1
EXT-CID 1
MSG2 2
02 * 2
03
04
05
06
07
08
09
10 * 1
11 * 1
01 * 3
