129
MAINTENANCE AND LUBRICATION
Spark Arrestor Clean-Out
Periodically clean the spark arrestor to remove accumulated carbon. Your vehicle has either
an end cap-type arrestor or a set screw-type arrestor. Perform the appropriate clean-out
procedure for your arrestor type.
End Cap-Type Arrestor
1. Remove the three screws (1) and remove the
arrestor (2) from the end of the muffler.
2. Use a non-synthetic brush to clean the arrestor
screen (3). A synthetic brush may melt if components
are warm. If necessary, blow debris from the screen
with compressed air.
3. Inspect the screen for wear and damage. Replace a
worn or damaged screen.
4. Remove and inspect the gasket (4). Replace a worn or damaged gasket.
5. Reinstall the gasket and arrestor. Torque screws to 50 in. lbs. (5.6 Nm).
1
2
3
4
