The parallel interface is based on the IEEE P1284-C standard.
If your computer has a parallel port, the printer driver and printer can take advantage
of faster data transfer.
Specifications
Pin configuration
Parallel Interface connector (printer side)
Notes:
B
“Return” denotes the return side wire of a twisted pair cable and is connected to
signal ground.
B Be sure to use only a shielded cable. The printer will not operate properly if any
of the pins is not connected.
IEEE 1284-C type connector
Signal Signal
Cable
+5V(Peripheral)
Use a shielded cable 2 m (6.6 ft.) or less in length.
nSelectin
Return
side pin
30
Appendix
Parallel Interface
Connector Type
19 Busy
Signal Pin
1
20 Select 2
21 nAck 3
22 nFault 4
23 PError 5
24 Data 1 6
25 Data 2 7
26 Data 3 8
27 Data 4 9
28 Data 5 10
29 Data 6 11
Data 7 12
31 Data 8
Signal Pin
Return
side pin
13
32 nInit 14
33 nStrobe 15
34 16
35 nAutoFd 17

+5V(Host) 18

36
18
36
1
19
