Pioneer DV-05 - Manual (Page 35)

35
Preparation
Basic
Operation
Setup
Other
Information
Detailed
Operation
Setup
Basic
Operation
Preparation
MAIN
STOP
MENU ENTER EXIT PREV ENTER
SETUP
2/2
OUTPUT
1 DOLBY DIGITAL
2 LINEAR PCM
3 MPEG
4 DTS
LPCM
48KHz
Changing Settings
Changing Settings
1. DOLBY DIGITAL: This player lets you change the audio output via an optical digital output jack and
a coaxial digital output jack. Selection of a DVD’s Dolby Digital audio (3-
dimensional audio used in theaters etc.) or Linear PCM (same digital audio as
that on CD) can be made.
Settings: DOLBY DIGITAL* (The Dolby Digital signal is output as is (when an
amplifier with built-in Dolby Digital (AC-3) decoder is used).)
DOLBY DIGITAL = PCM (Provides Linear PCM sound with both Dolby
Digital and Linear PCM sources (when a regular amp or Dolby Pro
Logic amp is used).)
2. LINEAR PCM: 96KHz: PCM audio discs with a 96KHz sampling frequency can be played back at
the 96KHz high quality sound setting. 48KHz discs will be played back at 48KHz.
48KHz: Discs with a 96KHz sampling frequency can be played back at a compressed
48KHz with this setting. 48KHz discs will be played back at 48KHz.
÷ When the audio sampling frequency recorded on the disc is set as desired, output
will also be switched between analog/digital output at the same time.
÷ Some 96 KHz DVDs are copy protected. With this kind of disc, no signal is output
from the digital output terminal.
Settings: 48KHz*
96KHz
3. MPEG: When a decoder or amplifier that has an MPEG input jack is used, the audio output
from this unit’s digital output jacks can be changed.
Selection of a DVD’s MPEG or linear PCM signal can be made.
Settings: MPEG
= PCM* (Output is in the linear PCM standard whether the signal
is an MPEG signal or a linear PCM compatible signal.)
MPEG: (MPEG signal is output as is. (When using an amplifier with a
built-in MPEG decoder.))
4. DTS: When using an amplifier that has a DTS input jack, the DTS signal can be set to be
output (ON) or not output (OFF) for DVDs that have been recorded with DTS signals.
Settings: OFF* (not Output)
ON (output DTS signals)
OUTPUT SETUP
Digital output setup is possible.
Audio output from the optical digital output jack and coaxial output jack of this unit can be changed.
Digital output can be turned on or off with the
2/3 buttons.
Settings: ON* (Digital audio is output)
OFF (Digital audio is not output)
The initial setting (set at the factory before shipping) has been set to ON.
÷ In each setting explanation, the setup mode first explained is the initial setting (set when shipped
from factory). (* is marked.)
MAIN
STOP
OUTPUT
MENU ENTER EXIT ENTER RETURN
1/2
1 DIG.OUTPUT DIG.OUTPUT
ON
Note
Do not change the output setting if you are not sure which system your amplifier is compatible with.
Set output setup to the setting that suits the component connected.
÷ Set to Dolby Digital for an AV amplifier compatible with DOLBY DIGITAL.
÷ Set to 96KHz for an AV amplifier compatible with 96 KHz linear PCM.
÷ Set to MPEG for an AV amplifier compatible with MPEG.
÷ Set to ON for an AV amplifier compatible with DTS.
MAIN
STOP
MENU ENTER EXIT PREV ENTER
SETUP
1/2
OUTPUT
1 DOLBY DIGITAL
2 LINEAR PCM
3 MPEG
4 DTS
DOLBY DIGITAL
DOLBY DIGITAL
MAIN
STOP
MENU ENTER EXIT PREV ENTER
SETUP
2/2
OUTPUT
1 DOLBY DIGITAL
2 LINEAR PCM
3 MPEG
4 DTS
MPEG
MPEG
= PCM
MAIN
STOP
MENU ENTER EXIT PREV ENTER
SETUP
2/2
OUTPUT
1 DOLBY DIGITAL
2 LINEAR PCM
3 MPEG
4 DTS
DTS
OFF
DIG. OUTPUT
