16 7976-A2-GZ40-00 March 1999
Configuring AutoRate
The M/SDSL AutoRate function is controlled from the Network Interface Options
screen and allows you to enable or disable AutoRate only from a unit configured
as an LTU. To access the Network Interface screen, follow this menu selection
sequence:
NOTE:
AutoRate is designed to find the best rate possible for your DSL loop
conditions. After the DSL loop is up units should be configured to run in fixed
rate.
Main Menu
→
Configuration
→
Network
О ОО
main/config/network Hotwire
Model: 7976
NETWORK INTERFACE OPTIONS
Margin Threshold: –3db
Excessive Error Rate Threshold: 1E–6
AutoRate Disable
DSL Line Rate 528
Peer IP Address: 111.255.255.000 Clear
Circuit Identifier: Clear
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
