33
Configure SCSI
ID
LUN
Mode
List SCSI IDs 0 thru
15 to be selected
from.
SCSI ID
C ONFIGURE SCSI
The Configure SCSI menu will allow the setting of SCSI parameters. The following
parameters are set in the configure SCSI menu:
Mode
SCSI ID
What you can do:
Press SEL: Selects one of the following active functions:
Mode
Move the display to the Mode menu.
SCSI ID
Move the display to the SCSI ID menu.
Press :
Moves the active message line up. (Active is marked by *.)
Press :
Moves the active message line down. (Active is marked by *.)
Press EXIT: Returns to the Configuration menu.
M
ODE
Select one of the following SCSI ID modes:
ID Selected
LUN
Selected toggles between these two when SEL is
pressed.
What you can do:
Press SEL: Selects one of the following active functions:
ID
Select device ID mode.
LUN
Select LUN (logical unit number) mode.
Press :
Moves the active message line up. (Active is marked by *.)
Press :
Moves the active message line down. (Active is marked by *.)
Press EXIT: Returns to the Configure SCSI menu.
See below
See page 34
