UltraTrak100 TX4 and UltraTrak100 TX8
User Manual
26
You will see the following message if all of the drives are already configured:
No Free Disk
What you can do:
Press SEL:
Pressing SEL will save the array.
Press
:
Does nothing.
Press
:
Does nothing.
Press EXIT:
Press EXIT to cancel this function and return to the Configure Array
menu.
V
IEW
D
RIVE
A
SSIGNMENTS
The View Drive Assignments mode lists each installed drive by model and
identifies its array ID or that it is free (if it is not assigned to an array). Each drive is
displayed on one line.
1 MAXTOR Asng In Ary 1
2 IBM Asng In Ary 2
Where the values shown are simply examples.
3 MAXTOR Asng In Ary 3
4 IBM Asng In Ary 4
Press
or
to move these items on the LCD.
What you can do:
Press SEL:
Does nothing.
Press
:
Moves the active message line up.
Press
:
Moves the active message line down.
Press EXIT: Returns
to
the
Configure Array menu.
