29
A
DD
/R
EMOVE
D
RIVES
The Add/Remove Drives menu assigns and removes drives from arrays. All free
drives are displayed as one drive per line format. The SEL key toggles the drive
between free and assigned. Assigned drives are designated by displaying
Assigned and free drives are designated by displaying Free.
1 MAXTOR Free
2 IBM Assigned
Where the values shown are simply examples.
3 MAXTOR Free
4 IBM Free
Press or to move these items on the LCD.
What you can do:
Press SEL: Toggles the selected drive between Free and Assigned.
Press :
Moves the active message line up.
Press :
Moves the active message line down.
Press EXIT: Returns to the Define Array menu.
D ELETE A RRAY
The Delete Array menu allows the user to select an array and delete the
configuration information for that array. This will also free any drives that have
been assigned to that array.
Array ID: 1
Only existing Array IDs are Displayed.
Array ID: 2
Array ID: 3
Array ID: 4
Press or to move these items on the LCD.
What you can do:
Press SEL: Displays a Delete Array confirmation message.
Press :
Moves the active message line up. (Active is marked by *.)
Press :
Moves the active message line down. (Active is marked by *.)
Press EXIT: Returns to the Configure Array menu.
